Set Up Your DIP Insertion Line with Our PCB Manual Insertion Conveyor
Are you looking to establish a DIP insertion line with manual PCB assembly but unsure about the right equipment? Look no further! Our PCB Manual Insertion Conveyor is the ideal solution for efficient manual PCB assembly processes.
Why Choose Our PCB Manual Insertion Conveyor?
Our PCB Manual Insertion Conveyor is specifically for hand insertion. It offers several features that enhance the assembly process:
LED lighting: The conveyor comes with 16W T8 LED lights that provide optimal lighting for operators. Facilitates accurate manual assembly and enhances overall assembly quality. Your operator can have a clear view.
Adjustable Width: The conveyor can be easily adjusted using a hand crank to accommodate PCBs of various widths. The PCB ranges from 50 mm to 350mm
Variable Speed Control: Our manual conveyor features a powerful 60W motor with an adjustable speed governor. Thus you can set the conveyor speed between 0.1 to 5 m/min or 0.5 to 2 m/min based on your production capacity.
Process Card Bracket: Each machine includes a process card bracket. Therefore, it ensures that operators have quick access to essential information during assembly.
Flexible Carrying Options: The equipment utilizes a chain system to transport PCBs or pallets. With an optional ESD belt for added safety and efficiency.
Custom Lengths Available: The standard conveyor length is 2.4 m or 3.0 m, but we offer customization to tailor it to your specific requirements.
Specification:
| Model | E-M2401 |
| Equipment size | Standard conveyor length=2.4m/segment; |
| Material placement table | The material placement table is designed to be detached on three sides. |
| Main body bracket | The rack made of 40×40mm rectangular aluminum profiles, and the guide rails of special aluminum |
| illumination | 16W single tube T8 LED lighting, evenly distributed throughout the line. |
| Transport | 60W motor driven; speed range adjustable from 0.5 to 2m/min. |
| Chain (Optinoal: ESD belt cusomizable) | |
| Work station profile | H type special aluminum profile for craft card aluminum, size: A4 paper; craft card aluminum |
| Distribution electric box | Each section is equipped with a control box to control lighting and conveyor belts; a set of standard one-open 8-hole sockets is installed next to the control cabinet. |
| Effective insertion width | Adjustment range is 50mm-350mm. (customizable) |
Enhance Your Manual PCB Assembly Process
Our PCB Manual Insertion Conveyor optimizes your manual assembly line. It also improves efficiency and precision. Perfect for DIP lines.
If you need other PCB board handling equipment, we can also help. Find them as below.
