Magazine Rack ESD, also known as SMT magazine rack, is widely used in SMT processing plants, PCB factories, and computer motherboard factories. It is resistant to acid, alkali, and oil, non-toxic and odorless, suitable for storing PCB boards. It facilitates convenient cleaning, easy circulation of circuit boards, neat stacking, and efficient management.
Features
With its rational design and superior quality, the Magazine Rack ESD is suitable for transportation, distribution, storage, and processing in factories, preventing static electricity on PCBs. It can be used in conjunction with various logistics containers and workstations in warehouses, production sites, and other scenarios, helping enterprises complete the circulation, storage, and integrated management of PCB boards. It is an excellent choice for modern production management in manufacturing and outsourcing enterprises.
Specification
| Model | E3532P |
| Adjustment method | Wrench adjustment |
| External dimensions: | 355*320*563mm |
| Base position: | A: 34mm; B: 34mm |
| Adjustable width: | 40-250mm |
| Groove depth: | 3.5mm |
| Groove width: | 7mm |
| Pitch: | 20 mm |
| Number of slots: | 25 |
| weight: | 4.3Kg |
| Carrying capacity: | 20kg |
| ◆Baffle mechanism: spring lever | |
| ◆Static electricity index: 10e4-10e8 | |
| ◆Side panel structure: 5 pieces of panels | |
| ◆Base plate material: plastic base plate | |
| 口100°C 口120°C 口150°C (Do not put it in the oven) | |
| □Metal folder | |
| port stacking screws | |
| □Layer label | |
| □Anti-sit label | |
Fine More Magazine Racks to suit your needs in below chart.
| Magazine Rack Dimension LxWxH (mm) | PCB Width(mm) | Slot Length(mm) | PCB Storage Qty(pcs) | Surface Resistance |
| 355x320x263 | 50-250 | 350 | 20 | Surface Resistance: 10^4-10^6 ohms System Resistance: <=10^9 ohms Test environment :25± RH: 55%±5% |
| 355x315x315 | 90-250 | 350 | 25 | |
| 355x315x365 | 90-250 | 350 | 30 | |
| 355x320x563 | 50-250 | 350 | 50 | |
| 355x320x565 | 50-240 | 350 | 50 | |
| 465x400x563 | 50-330 | 460 | 50 | |
| 535x460x570 | 50-390 | 530 | 50 | |
| 535x530x570 | 120-460 | 530 | 50 |
The Magazine Rack ESD effectively dissipates static charges accumulated on the surface of PCBs, providing protection for PCBs and electronic components. It is designed rationally with excellent quality. It is suitable for transportation, distribution, storage, and processing in SMT factories. Our ESD Magazine Rack is made of high-quality aluminum alloy material, with low density, high strength, comparable to or exceeding high-quality steel. Besides, the PCB magazine rack has good plasticity, can be processed into various profiles, and exhibits excellent conductivity, heat conduction, and corrosion resistance. It is sturdy, durable, and has a long service life. It is easy to install with low maintenance costs. Various custom sizes of Magazine Racks ESD can be made to meet specific user requirements. Its width is adjustable to accommodate various PCB sizes. It has a large capacity for storing multiple PCBs. It has strong load-bearing capacity. Its precise dimensions and slot accuracy, upgraded widened slot spacing, are suitable for thick PCB circuit boards. Screw adjustment design prevents loosening, ensuring PCBs remain secure. The hexagonal screw track adjustment allows for flexible width adjustments when placing boards.
