We are YEETAI based in China. We offer KIC START Temperature Profiler is an entry-level, high-performance device specifically designed for measuring temperature curves in various industrial applications. This versatile profiler is ideal for processes such as solder paste reflow, adhesive curing, wave soldering, and repair stations. With its cost-effectiveness and user-friendly operation, the KIC START is perfect for general Surface Mount Technology (SMT) manufacturing plants.
Key Features of the KIC START Temperature Profiler
- Affordable Price: A budget-friendly solution for temperature profiling needs.
- Quick and Precise Curve Plotting: Enables rapid and accurate temperature data collection.
- Instant Objective Curve Analysis: Provides immediate feedback for process optimization.
- User-Friendly Software: Intuitive interface for easy data management and analysis.
- Reliable and Sturdy Hardware: Built to withstand industrial environments.
- 24-Hour Customer Support: Dedicated assistance to ensure optimal performance.
Product Specifications
- Accuracy: +/- 1.2℃
- Resolution: 0.3℃ to 0.1℃
- Internal Operating Temperature: 0℃ to 105℃
- Compatible Thermocouples: 6 K-type thermocouples
- Measurement Temperature Range: -150℃ to 1050℃
- System Compatibility: Fully compatible with PCs
- Power Supply: 9-volt alkaline battery
- Dimensions (with standard insulation cover): 320mm (L) x 86mm (W) x 26mm (H)
- Brand: KIC (USA)
- Item Number: 1
- Model: START 6-Channel,8- Channel
- Type: Online
- Applicable Object: Industrial Temperature Measurement Instrument
- Measurement Range: -150 to 1050 degrees
- Measurement Accuracy: +/- 0.1 degrees
- Display Method: PC
- Battery Type: 9V alkaline battery
- Material: Metal
- Response Time: 1 minute
- Net Weight: 1 kg
Applications in SMT Manufacturing
The KIC START Temperature Profiler is essential for ensuring the quality and reliability of SMT processes. By accurately measuring temperature profiles, manufacturers can optimize their production lines, reduce defects, and enhance overall efficiency. This device is a valuable tool for quality control in various applications, including:
- Solder Paste Reflow: Ensures optimal melting and adhesion of solder paste.
- Adhesive Curing: Monitors temperature during curing processes for strong bonds.
- Wave Soldering: Provides precise temperature control for effective soldering.
- Repair Stations: Aids in troubleshooting and repairing electronic components.
Our packing List
| 1） | KIC Temperature Profiler | 1 |
| 2） | Thermometer Insulated Housings | 1 |
| 3） | suitcase | 1 |
| 4） | a thermometer cable | 6 |
| 5） | User manual | 1 |
| 6） | data CD | 1 |
| 7） | data transmission cable | 1 |
Why Choose the KIC START Temperature Profiler?
Choosing the KIC START Temperature Profiler means investing in a reliable and efficient tool that simplifies temperature profiling. Its combination of affordability, ease of use, and robust features makes it an excellent choice for both small and large manufacturing operations.
Get Started Today!
To learn more about our Profiler and how it can benefit your SMT manufacturing processes, contact us for more information or to request a demo.
