ESD SMT PCB Rack E9030P made of High-quality raw materials with anti-static agents, providing essential ESD protection for sensitive electronic components.These ESD magazine racks are suitable for various electronic processing fields, including electronic component production, assembly, testing, and more. They effectively prevent static electricity from damaging electronic components, improve production efficiency, and are an ideal choice for electronic manufacturing enterprises. The main purpose is to eliminate static electricity, widely used in the turnover loading, packaging, storage, and transportation of electronic devices and products during the production process.
Specification
| Adjustment method | Screw adjustment | |
| Specifications | ●Outer dimensions: | 355*31 5*365mm |
| ●Reference position: | A: 34mm; B: 35.5mm | |
| ●Adjustable width: | 90-250mm | |
| ●Groove depth: | 3.5mm | |
| ●Slot width: | 7mm | |
| ●Pitch: | 10mm | |
| ●Number of slots: | 30 | |
| ●Weight: | 3.55Kg | |
| ●Carrying: | 12kg | |
| Product Description | ◆Baffle mechanism: spring lever | |
| ◆Static electricity index: 10e4-10e8 | ||
| ◆Side panel structure: full page | ||
| ◆Base plate material: plastic base plate | ||
| Temperature resistant | 口80°C | |
| Optional accessories | Poka-yoke labels | |
Fine More Magazine Racks to suit your needs in below chart.
| Magazine Rack Dimension LxWxH (mm) | PCB Width(mm) | Slot Length(mm) | PCB Storage Qty(pcs) | Surface Resistance |
| 355x320x263 | 50-250 | 350 | 20 | Surface Resistance: 10^4-10^6 ohms System Resistance: <=10^9 ohms Test environment :25± RH: 55%±5% |
| 355x315x315 | 90-250 | 350 | 25 | |
| 355x315x365 | 90-250 | 350 | 30 | |
| 355x320x563 | 50-250 | 350 | 50 | |
| 355x320x565 | 50-240 | 350 | 50 | |
| 465x400x563 | 50-330 | 460 | 50 | |
| 535x460x570 | 50-390 | 530 | 50 | |
| 535x530x570 | 120-460 | 530 | 50 |
Advantages:
- ESD Magazine Racks are designed with conductive materials to effectively dissipate static charges and prevent ESD events, ensuring the safety of electronic components.
- They provide organized and efficient storage for PCBs, allowing for easy identification and retrieval during manufacturing processes.
- The adjustable slots in ESD SMT PCB Racks accommodate various PCB sizes and thicknesses, offering versatility and flexibility in storage options.
- These racks help improve workflow efficiency by reducing the risk of damage to PCBs, minimizing production downtime, and enhancing overall productivity.
- ESD SMT PCB Racks are durable, reusable, and environmentally friendly, making them a cost-effective solution for ESD protection in electronics manufacturing operations.
Welcome to visit our factory to learn more about ESD SMT PCB Rack. If you would like to have a deeper understanding of ESD Magazine Rack, you are welcome to visit our factory. Our company has high-quality electrostatic professionals and management team, as well as strong R&D capabilities. For many years, we have been dedicated to the research, production, and sales of antistatic consumables such as ESD Magazine Rack, ESD PCB Storage Trolley, ESD Chair, etc. With high-quality products and excellent services, we have received consistent praise from customers and have become a leading company in the antistatic industry with significant influence in the industry.
Our factory is equipped with multiple granulation equipment, over ten injection molding machines, and forming machines; we have also invested in multiple lathes, milling machines, punching machines, laser cutting, and other metal equipment for the production of ESD Magazine Rack. Our outstanding mechanical capabilities ensure the excellent quality of our products, which are exported to countries in Europe, America, and Southeast Asia.
The ESD Magazine Rack produced by our company strictly complies with international standards such as IEC 61340-5-1, ANSI/ESD-S20.20, and the international military standard GJB3007-2009. We have passed the strict implementation of the ISO 9001:2015 quality management system, ISO 14001:2015 environmental management system, and the product materials have been inspected by SGS to comply with the requirements of the ROHS 2.0 EU environmental directive.
